Omada BE3600 Ceiling Mount Dual-Band Wi-Fi 7 Access Point PORT: 1×2.5G RJ45 Port SPEED: 688Mbps at 2.4 GHz + 2880 Mbps

Popis produktu:

BE3600 Dual-Band Wi-Fi 7 (2882 Mb/s na 5 GHz + 688 Mb/s na 2,4 GHz). 1× 2,5GbE port odomyká plný potenciál Wi-Fi 7.
Šírka pásma 160 MHz umožňuje oveľa viac simultánnych prenosov.‡Multi-RUs zabezpečujú vysoký výkon vašej siete.
Pokročilé funkcie: Centralizovaná správa, Mesh a plynulý roaming.

HARDWARE FEATURES
Interface 1× 2.5G Ethernet Port
Button Reset
Power Supply 802.3at PoE or 12V/1.5A DC (Power Adapter Is Not Included)
Max. Power Consumption • 18.6 W (For PoE);
• 16.0 W (For DC)
Dimensions ( W x D x H ) 6.3 × 6.3 × 1.4 in (160 × 160 × 36.7 mm)
Antenna • 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
Mounting Ceiling / Wall Mounting (Kits Included)
WIRELESS FEATURES
Coverage 140?(1500 ft2)***
Concurrent Clients 250+**
Wireless Standards IEEE 802.11 a/b/g/n/ac/ax/be
Frequency 2.4 GHz and 5 GHz
Signal Rate 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz)
Wireless Functions • 4K-QAM‡
• Seamless Roaming
• MU-MIMO‡
• EHT160‡
• Mesh?
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:16(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
Wireless Security • Captive Portal Authentication?
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power < 20 dBm (2.4 GHz, EIRP)
< 23 dBm (5 GHz, band 1&band 2, EIRP)
< 28 dBm (5 GHz, band 3, EIRP)

Management Features
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
System Logging Local/Remote Syslog Yes
Web-based Management Yes
OTHERS
Certification CE, FCC, RoHS, IC
Package Content • EAP723
• Installation Guide
• Ceiling/Wall Mounting Kit
Environment • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;

Technické špecifikácie sa môžu meniť bez predošlého upozornenia. Obsah aktuálneho balenia sa môže líšiť v závislosti od dátumu predaja. Obrázky majú len informatívny charakter.
